F4 corrugation compensator

F4 corrugation compensator is used to compensate the error caused by cooling /heated odf pipe , or used in soft connection to reduce the damage caused by shocks of pump and air blow

F4 corrugation compensator
Type
1.Common type ： F4+rubber+ high strength spring steel reinforced F4 corrugation compensator
2. Stainless steel composite type ： F4 corrugation compensator made by F4+ rippled stainless stee. Anti- negative pressure type ： A/ B type of F4 corrugation compensator with F4 coated typesetting ring inside

Type and meaning

Note：Number of ripple- 2, 3…6 etc

Nominal diameter		Standard length L(mm)	Nominal pressure PN(MPa)	technical parameters			flange			weight
DN (mm)	NPS (in)	Standard length L(mm)	Nominal pressure PN(MPa)	±△X(mm)	±△Y(mm)	a	D1 (mm)	φ (mm)	n	kg
40	11/2	190	1.6	3.5	1.5	14	110	18	4	6.9
50	2	210		4.5	1.5	12	125	18	4	9.2
65	21/2	225		5	1.5	10	145	18	4	12.5
80	3	235		6	2	12	160	18	8	16.2
100	4	300		4.6	1.8	5	180	18	8	19
15	6	300		4.4	1.6	5	240	23	8	28
200	8	400		8	1.2	5	295	23	12	38
250	10	400		7.5	1	5	355	25	12	58
300	12	450		8	1	5	410	25	12	76
350	14	450		8	1	5	170	25	16	96
400	16	450		8	0.8	4	525	25	16	118
450	18	450		8	0.4	3.5	585	30	20	144
500	20	500		8	0.7	3.2	650	30	20	204
600	24	600		13	1.8	4	770	34	20	263
700	28	600	0.6	24	1.6	7.2	810	41	24	173
800	32	600		24	2.2	6	920	25	24	212
900	36	700		23	1.9	5.2	1020	30	24	265
1000	40	700		22	1.6	4.8	1120	30	28	306
1200	48	700	0.25	38	2.4	6.6	1320	30	32	383
1400	56	700		37	2	5.6	1520	30	36	445
1600	64	700		36	1.7	4.8	1730	30	40	526
